By suspending the rider with damped, tunable travel—20mm front/30mm rear—Future Shock Technology absorbs bump forces to boost your control and capability while retaining the efficiency and responsiveness of a rigid frame. Because as far as power transfer goes, it is a rigid frame. Power to the pedals makes the bike jump like a scared cat. You’re efficient, you’re comfortable, you’re in control. Your bike is light, nimble, and responsive.
Born from decades of innovation and our Smoother is Faster philosophy, Future Shock was created to develop bikes that win on cobblestones, but it’s found its purest expression on gravel. It’s 20mm of adjustable, damped front travel that keeps you in control and on target, all while protecting your hands, arms, and shoulders from the battering.
More capability means more confidence, more confidence means more rides, more rides mean more fun, and it all starts at the contact patch. Nothing unlocks capability like tire clearance, and we’re feeling generous. 47mm on a 700c wheel and 2.1” on 650B. Diverge STR is the most capable gravel bike we’ve ever made, so it’s the most fun. We did the math.
Diverge FACT 11r carbon frameset with front and rear Future Shock suspension, SWAT™ Door integration, threaded BB, internal routing, 12x142mm thru-axle, flat-mount disc
Future Shock 3.3 w/ Damper, Smooth Boot, FACT carbon, 12x100 mm thru-axle, flat-mount
Future Stem, Pro
Roval Terra, carbon, 103mm drop x 70mm reach x 12º flare
SRAM Force, hydraulic disc, 160mm Paceline rotor
SRAM Force, hydraulic disc, 160mm Paceline rotor
SRAM Force eTap AXS
SRAM X01 Eagle AXS
SRAM Force 1x
SRAM X01 Eagle, 12-speed
40T
Supacaz Super Sticky Kush
Integrated SWAT door, internal storage system
S-Works Carbon Seat Post, 20mm Offset
Specialized Alloy, 33.3mm
Body Geometry Power Pro, hollow titanium rails
Roval Terra CL, 25mm internal width, 32mm depth, 24h, Tubeless ready, DT for Roval 350 hub, Centerlock disc, DT Swiss Competition Race spokes
Tracer Pro 2BR, 700x42
Tracer Pro 2BR, 700x42
700x28/38mm, 48mm Presta valve
Roval Terra CL, 25mm internal width, 32mm depth, 24h, Tubeless ready, DT for Roval 350 hub, Centerlock disc, DT Swiss Competition Race spokes
Roval Terra CL, 25mm internal width, 32mm depth, 24h, Tubeless ready, DT for Roval 350 hub, Centerlock disc, DT Swiss Competition Race spokes
SRAM DUB BSA 68
SRAM DUB BSA 68
